Type: Pool
Material: Lucite Acrylic
Thickness: 20-300mm Customized
Density: 1.2g/Cm3
Surface: High Surface Hardness
Shape: Customer's Demand
Light Transmission: High Light Transmission(95%)
Diaphaneity: More Than 93%
Brand Name: Jinsui
Place Of Origin: Jiangsu, China
Packaging: 1.Covered with craft paper or PE film on both size. 2. two tons/tray, cover packaging film on each tray and use steel pallets for protection 3. 18-20 tons/ 20'GP, total 10 trays.
Supply Ability: 400 tons per month
Port: Shanghai
Payment Type: L/C,T/T,MoneyGram
The Acrylic Swimming Pool Panel is placed in the sun, but it can withstand the wind, the sun and the rain. The Acrylic Sheet is designed seamlessly, and no flaws or gaps can be seen, which conforms to the beautification concept.
Test tensile strength and Vicat softening temperature for each production batch.
Through finite element analysis, determine the thickness of the acrylic, and draw the design for you.
Products Description
Material | Lucite Acrylic |
Thickness | 20-300mm customized |
Color | Clear/transparent |
Shape | Customer's Demand |
Surface | High Surface Hardness |
Light transmission | High light transmission (93%) |
Diaphaneity | More than 92% |
Packing | PE film masking on both sides, KT board and angle iron. |
Application | Undersea world, Oceanarium, Zoo, Luxurious hotels, Swimming pools and so on. |
PROPERTIES | VALUES | RULES |
Density | 1.19 g/cm3 | ISO 1183-1:2012 Method A |
Rockwell Hardness | 112L | ISO 2039-2:1999 |
Tensile Modulus | 3150MPa | EN ISO 527:2012 |
Tensile Strength | 80.0MPa | EN ISO 527:2012 |
Tensile Strain at Break | 3.2% | EN ISO 527-1:2012 |
Water Absorption | 0.20% | ISO 62:2008 Method 1 |
Total Luminous Transmittance | 93.4% | ISO 13468-1:1996 |
Vicat Softening Temperature | 105℃ | ISO 306:2013 Method B50 |
Light Ageing Test- UV Exposure | Grey scale: 5 | ISO 4892-3:2016 Cycle 1 |
Mean Coefficient of Linear Thermal Expansion | 72×10-6 K-1 | ISO 11359-1:2014 |
Compressive Stress at Yield | 129MPa | EN ISO 604:2003 |
Flexural Strength | 120MPa | ISO 178:2013 |
Compressive Yield Strength | 111MPa | ASTM D695-15 |
Compressive Modulus | 3450MPa | ASTM D695-15 |
Shear Strength | 59.7MPa | ASTM D732-17 |
Deflection Temperature under Load | 100.2℃ | ASTM D648-18 Method B |
Modulus Elasticity | 2810MPa | ASTM D695-15 |
Product Categories : Container Pool
