JINSUI
Type: Pool
Products Type: Acrylic sheet
Materials: Pmma, Acrylic
Light Transmission: High Light Transmission (93%)
Brand Name: Jinsui
Place Of Origin: Jiangsu, China
Resistant: Excellent Resistance to Weather
Packing: Both Sides Covered by PE Film or Craft Paper
Process: Laser Engraving, CNC, Thermoforming
Thickness: 50mm to 300mm
Density: 1.19-1.20g/cm3
Packaging: 1.Covered with craft paper or PE film. 2. two tons/tray, cover packaging film on each tray and use steel pallets for protection. 3. 18-20 tons/ 20'GP, total 10 trays.
Transportation: Ocean
Supply Ability: 3000 Ton/Tons per Month
Port: Shanghai
Payment Type: L/C,T/T
Incoterm: FOB,CIF,EXW
Test tensile strength and Vicat softening temperature for each production batch.
Through finite element analysis, determine the thickness of the acrylic sheet, and draw the design for you.
We provide you with the acrylic sheet installation guide, if necessary, our engineers can come to your side to install.
Products Description
| Material | Lucite Acrylic |
| Thickness | 20-300mm customized |
| Color | Clear/transparent |
| Shape | Customer's Demand |
| Surface | High Surface Hardness |
| Light transmission | High light transmission (93%) |
| Packing | PE film masking on both sides, KT board and angle iron. |
| Application | Undersea world, Oceanarium, Zoo, Luxurious hotels, Swimming pools and so on. |
| PROPERTIES | VALUES | RULES |
| Density | 1.19 g/cm3 | ISO 1183-1:2012 Method A |
| Rockwell Hardness | 112L | ISO 2039-2:1999 |
| Tensile Modulus | 3150MPa | EN ISO 527:2012 |
| Tensile Strength | 80.0MPa | EN ISO 527:2012 |
| Tensile Strain at Break | 3.2% | EN ISO 527-1:2012 |
| Water Absorption | 0.20% | ISO 62:2008 Method 1 |
| Total Luminous Transmittance | 93.4% | ISO 13468-1:1996 |
| Vicat Softening Temperature | 105℃ | ISO 306:2013 Method B50 |
| Light Ageing Test- UV Exposure | Grey scale: 5 | ISO 4892-3:2016 Cycle 1 |
| Mean Coefficient of Linear Thermal Expansion | 72×10-6 K-1 | ISO 11359-1:2014 |
| Compressive Stress at Yield | 129MPa | EN ISO 604:2003 |
| Flexural Strength | 120MPa | ISO 178:2013 |
| Compressive Yield Strength | 111MPa | ASTM D695-15 |
| Compressive Modulus | 3450MPa | ASTM D695-15 |
| Shear Strength | 59.7MPa | ASTM D732-17 |
| Deflection Temperature under Load | 100.2℃ | ASTM D648-18 Method B |
| Modulus Elasticity | 2810MPa | ASTM D695-15 |
